Key benefits:
- Economy of raw materials; uniform sintering, faster machining time, lower cost.
- Economically better compared to machining a solid billet.
- Manufacturing can be done in diameters and heights close to the final measurement.
Applications:
- Manufacture of gaskets, bearings, coatings
- Manufacture of sealing rings, gaskets for flanges and hydraulics
- Manufacture of Gaskets and Seals
- Manufacture of valve ball seats
- Valve body coating
- Use in the maintenance of Industrial Pumps
Table:
| Ø External | Ø Internal | Max. Height | ||
| (mm) | (in) | (mm) | (in) | (mm) |
| 51.0 | 2.0 | 25.0 | 1.0 | 200.0 |
| 51.0 | 2.0 | 31.0 | 1.3 | 150.0 |
| 57.0 | 2,3 | 25.0 | 1.0 | 250.0 |
| 57.0 | 2,3 | 31.0 | 1.3 | 200.0 |
| 57.0 | 2,3 | 44.0 | 1.8 | 100.0 |
| 63.5 | 2.5 | 25.0 | 1.0 | 300.0 |
| 63.5 | 2.5 | 31.0 | 1.3 | 250.0 |
| 63.5 | 2.5 | 44.0 | 1.8 | 150.0 |
| 63.5 | 2.5 | 50.0 | 2.0 | 108.0 |
| 70.0 | 2.8 | 25.0 | 1.0 | 300.0 |
| 70.0 | 2.8 | 31.0 | 1.3 | 300.0 |
| 70.0 | 2.8 | 44.0 | 1.8 | 200.0 |
| 70.0 | 2.8 | 50.0 | 2.0 | 150.0 |
| 76.0 | 3.0 | 25.0 | 1.0 | 300.0 |
| 76.0 | 3.0 | 31.0 | 1.3 | 300.0 |
| 76.0 | 3.0 | 44.0 | 1.8 | 250.0 |
| 76.0 | 3.0 | 50.0 | 2.0 | 200.0 |
| 76.0 | 3.0 | 57.0 | 2,3 | 150.0 |
| 83.0 | 3.3 | 31.0 | 1.3 | 300.0 |
| 83.0 | 3.3 | 44.0 | 1.8 | 300.0 |
| 83.0 | 3.3 | 50.0 | 2.0 | 250.0 |
| 83.0 | 3.3 | 63.0 | 2.5 | 150.0 |
| 83.0 | 3.3 | 70.0 | 2.8 | 100.0 |
| 89.0 | 3.5 | 31.0 | 1.3 | 300.0 |
| 89.0 | 3.5 | 50.0 | 2.0 | 300.0 |
| 89.0 | 3.5 | 63.0 | 2.5 | 200.0 |
| 89.0 | 3.5 | 70.0 | 2.8 | 150.0 |
| 102.0 | 4.0 | 31.0 | 1.3 | 300.0 |
| 102.0 | 4.0 | 50.0 | 2.0 | 300.0 |
| 102.0 | 4.0 | 70.0 | 2.8 | 250.0 |
| 102.0 | 4.0 | 82.0 | 3.3 | 150.0 |
| 115.0 | 4.5 | 50.0 | 2.0 | 300.0 |
| 115.0 | 4.5 | 63.0 | 2.5 | 300.0 |
| 115.0 | 4.5 | 76.0 | 3.0 | 300.0 |
| 115.0 | 4.5 | 89.0 | 3.5 | 300.0 |
| 127.0 | 5.0 | 50.0 | 2.0 | 300.0 |
| 127.0 | 5.0 | 63.0 | 2.5 | 300.0 |
| 127.0 | 5.0 | 76.0 | 3.0 | 300.0 |
| 127.0 | 5.0 | 89.0 | 3.5 | 300.0 |
| 127.0 | 5.0 | 101.0 | 4.0 | 300.0 |
| 140.0 | 5.5 | 50.0 | 2.0 | 300.0 |
| 140.0 | 5.5 | 63.0 | 2.5 | 300.0 |
| 140.0 | 5.5 | 76.0 | 3.0 | 300.0 |
| 140.0 | 5.5 | 89.0 | 3.5 | 300.0 |
| 140.0 | 5.5 | 101.0 | 4.0 | 300.0 |
| 140.0 | 5.5 | 114.0 | 4.5 | 300.0 |
| 152.0 | 6.0 | 50.0 | 2.0 | 300.0 |
| 152.0 | 6.0 | 76.0 | 3.0 | 300.0 |
| 152.0 | 6.0 | 89.0 | 3.5 | 300.0 |
| 152.0 | 6.0 | 101.0 | 4.0 | 300.0 |
| 152.0 | 6.0 | 127.0 | 5.0 | 300.0 |
| 165.0 | 6.5 | 50.0 | 2.0 | 300.0 |
| 165.0 | 6.5 | 76.0 | 3.0 | 300.0 |
| 165.0 | 6.5 | 101.0 | 4.0 | 300.0 |
| 165.0 | 6.5 | 127.0 | 5.0 | 300.0 |
| 165.0 | 6.5 | 140.0 | 5.5 | 300.0 |
| 178.0 | 7.0 | 50.0 | 2.0 | 300.0 |
| 178.0 | 7.0 | 82.0 | 3.3 | 300.0 |
| 178.0 | 7.0 | 114.0 | 4.5 | 300.0 |
| 178.0 | 7.0 | 140.0 | 5.5 | 300.0 |
| 178.0 | 7.0 | 152.0 | 6.0 | 300.0 |
| 190.0 | 7.5 | 50.0 | 2.0 | 300.0 |
| 190.0 | 7.5 | 76.0 | 3.0 | 300.0 |
| 190.0 | 7.5 | 101.0 | 4.0 | 300.0 |
| 190.0 | 7.5 | 140.0 | 5.5 | 300.0 |
| 190.0 | 7.5 | 165.0 | 6.5 | 300.0 |
| 203.0 | 8.0 | 63.0 | 2.5 | 300.0 |
| 203.0 | 8.0 | 89.0 | 3.5 | 300.0 |
| 203.0 | 8.0 | 127.0 | 5.0 | 300.0 |
| 203.0 | 8.0 | 152.0 | 6.0 | 300.0 |
